Description
| Parameter |
Specification for GE-F120-2H2
|
| Nominal Output Power / UPS
Power (W) |
50000 |
| AC Output Frequency and Voltage
|
50 / 60Hz; 220 / 380, 230 /
400Vac |
| Grid Type |
3L / N / PE |
| Number of Parallel (Off-grid)
|
10 |
| Energy Configuration (kWh) |
122.8 |
| Dimension (W × D × H, mm) |
1780 × 1056 × 2235 |
| Weight Approximate (kg) |
2090 |
| AC Output Rated Current (A)
|
75.8 |
| Battery Operating Voltage (V)
|
500 ~ 700 |
| Max. RTE |
89% |
| Battery Chemistry |
LiFePO₄ |
| IP Rating of Enclosure |
IP55 |
| Installation Method |
Floor-Mounted |
| Storage Temperature (°C) |
0 ~ 35 |
| Operating Temperature (°C) |
-20 ~ 55 (>43 derating) |
| Warranty |
10 years |
- Power and Output: Boasting a nominal output power of 50,000 W, it
delivers AC output at 50/60Hz with voltages 220/380, 230/400Vac, ensuring stable
power supply for various applications. The AC output rated current reaches 75.8 A,
meeting high – power demand effortlessly.
- Safety and Longevity: It utilizes LiFePO₄ batteries, renowned for
safety and durability. With ≥6000 cycles and 70% EOL (End – of – Life) capacity
retention, plus 5 – level extreme safety protection and a 10 – year warranty, it
guarantees long – term reliable operation.
- Flexibility and Integration: Supporting battery expansion up to
3600 kWh (off – grid) and featuring integrated technology like EMS, hybrid inverter,
and BMS integration, along with power supply redundancy design and black start/off –
grid operation capabilities, it adapts to diverse energy needs.
- Specifications: With an energy configuration of 122.8 kWh,
dimensions of 1780×1056×2235 mm, and a weight of around 2090 kg, it’s floor –
mounted for easy installation. Operating within a temperature range of – 20 ~ 55°C
(>43°C with derating) and storage temp of 0 ~ 35°C, it suits various
environments.
