| Battery
Input Data |
| Battery Type |
Lithium-ion |
| Battery Voltage Range (V) |
160-800 |
| Max. Charging Current (A) |
50+50 |
| Max. Discharging Current (A)
|
50+50 |
| Charging Strategy for Li-ion
Battery |
Self-adaption to
BMS |
| Number of Battery Input |
2 |
| PV String
Input Data |
| Max. PV Access Power (W) |
59800 |
60000 |
70000 |
80000 |
100000 |
| Max. PV Input Power (W) |
47840 |
48000 |
56000 |
64000 |
80000 |
| Max. PV Input Voltage (V) |
1000 |
| Start-up Voltage (V) |
180 |
| MPPT Voltage Range (V) |
150-850 |
| Rated PV Input Voltage (V) |
600 |
| Max. Operating PV Input Current
(A) |
36+36+36 |
36+36+36+36 |
| Max. Input Short-Circuit
Current (A) |
55+55+55 |
55+55+55+55 |
| No. of MPP Trackers/ No. of
Strings/MPP Tracker |
3/2+2+2 |
4/2+2+2+2 |
| AC
Input/Output Data |
| Rated AC Input/Output Active
Power (W) |
29900 |
30000 |
35000 |
40000 |
50000 |
| Max. AC Input/Output Apparent
Power (VA) |
29900 |
33000 |
38500 |
44000 |
55000 |
| Rated AC Input/Output Current
(A) |
45.4/43.4 |
45.5/43.5 |
53.1/50.8 |
60.7/58 |
75.8/72.5 |
| Max. AC Input/Output Current
(A) |
45.4/43.4 |
50/47.9 |
58.4/55.8 |
66.7/63.8 |
83.4/79.8 |
| Max. Continuous AC Passthrough
(grid to load) (A) |
200 |
| Peak Power (off-grid) (W) |
1.5 times of rated
power, 10s |
| Power Factor Adjustment Range
|
0.8 leading to 0.8
lagging |
| Rated Input/Output
Voltage/Range (V) |
220/380V, 230/400V
0.85Un-1.1Un |
| Rated Input/Output Grid
Frequency/Range(Hz) |
50/45-55, 60/55-65
|
| Grid Connection Form |
3L+N+PE |
| Total Current Harmonic
Distortion THDi |
<3% (of nominal
power) |
| DC Injection Current |
<0.5% In |
