| Battery
Input Data |
| Battery Type |
Lead-acid or
Lithium-ion |
| Battery Voltage Range (V) |
40-60 |
| Max. Charging Current (A) |
90 |
120 |
135 |
175 |
190 |
190 |
210 |
| Max. Discharging Current (A)
|
90 |
120 |
135 |
175 |
190 |
190 |
210 |
| Charging Strategy for Li-ion
Battery |
Self-adaption to BMS
|
| Number of Battery Input |
1 |
| PV String
Input Data |
| Max. PV Access Power (W) |
7200 |
10000 |
12000 |
14000 |
15200 |
16000 |
20000 |
| Max. PV Input Power (W) |
5760 |
8000 |
9600 |
11200 |
12160 |
12800 |
16000 |
| Max. PV Input Voltage (V) |
500 |
| Start-up Voltage (V) |
125 |
| MPPT Voltage Range (V) |
150-425 |
| Rated PV Input Voltage (V) |
370 |
| Max. Operating PV Input Current
(A) |
13+13 |
26+26 |
| Max. Input Short-Circuit
Current (A) |
17+17 |
34+34 |
| No. of MPP Trackers/ No. of
Strings MPP Tracker |
2/1+1 |
2/2+2 |
| AC
Input/Output Data |
| Rated AC Input/Output Active
Power (W) |
3600 |
5000 |
6000 |
7000 |
7600 |
8000 |
10000 |
| Max. AC Input/Output Apparent
Power (VA) |
3960 |
5500 |
6600 |
7700 |
8360 |
8800 |
11000 |
| Rated AC Input/Output Current
(A) |
16.4/15.7 |
22.7/21.7 |
27.3/26.1 |
31.9/30.5 |
34.5/33 |
36.4/34.8 |
45.5/43.5 |
| Max. AC Input/Output Current
(A) |
18/17.2 |
25/23.9 |
30/28.7 |
35/33.5 |
38/36.3 |
40/38.3 |
50/47.9 |
| Max. Continuous AC Passthrough
(grid to load) (A) |
35 |
40 |
50 |
| Peak Power (off-grid) (W) |
2 times of rated
power, 10s |
| Power Factor Adjustment Range
|
0.8 leading to 0.8
lagging |
| Rated Input/Output
Voltage/Range (V) |
220/230 0.85Un-1.1Un
|
| Rated Input/Output Grid
Frequency/Range(Hz) |
50/45-55, 60/55-65
|
| Grid Connection Form |
L+N+PE |
| Total Current Harmonic
Distortion THDi |
<3% (of nominal
power) |
| DC Injection Current |
<0.5% In |
|
Efficiency
|
| Max. Efficiency |
97.6% |
| Euro Efficiency |
96.5% |
| MPPT Efficiency |
>99% |
