PV String Input Data
|
| Max. PV Input Power (kW) |
90 |
105 |
112.5 |
120 |
| Max. PV Input Voltage (V) |
1100 |
| Start-up Voltage (V) |
250 |
| MPPT Voltage Range (V) |
200-1000 |
| Rated PV Input Voltage (V) |
600 |
720 |
| Max. Operating PV Input Current (A) |
40+40+40+40 |
| Max. Input Short Circuit Current (A)
|
60+60+60+60 |
No. of MPP Trackers/
No. of Strings/ MPP Tracker
|
4/3+3+3+3 |
4/4+4+4+4 |
|
AC Output Side
|
| Rated AC Output Active Power (kW) |
60 |
70 |
75 |
80 |
| Max. AC Output Apparent Power (kVA) |
66 |
77 |
82.5 |
88 |
| Rated AC Output Current (A) |
90.9/87 |
106.7/101.5 |
113.6/108.7 |
121.2/115.9 |
| Max. AC Output Current (A) |
100/95.7 |
116.7/111.6 |
125/119.6 |
133.3/127.3 |
| Rated Output Voltage/Range (V) |
220/380V, 230/400V 0.85Un-1.1Un |
| Grid Connection Form |
3L/N/PE |
| Rated Output Grid Frequency/Range(Hz)
|
50/45-55, 60/55-65 |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Total Current Harmonic Distortion THDi
|
<3% |
| DC Injection Current |
<0.5%In |
|
Efficiency
|
| Max. Efficiency |
98.6% |
98.7% |
| Euro Efficiency |
98.0% |
98.1% |
| MPPT Efficiency |
>99% |
|
Equipment Protection
|
| DC Reverse Polarity Protection |
Yes |
| AC Output Overcurrent Protection |
Yes |
| AC Output Overvoltage Protection |
Yes |
| AC Output Short Circuit Protection |
Yes |
| Thermal Protection |
Yes |
| Insulation Impedance Detection |
Yes |
| DC Component Monitoring |
Yes |
| Arc-Fault Circuit Interrupter (AFCI)
|
Optional |
| Anti-islanding Protection |
Yes |
| Residual Current Detection |
Yes |
| Surge Protection Level |
TYPE II(DC), TYPE III(AC) |
| DC Switch |
Yes |
