| Battery Input Data |
| Battery Type |
Lead-acid or Lithium-ion |
| Battery Voltage Range (V) |
40-60 |
| Max. Charging Current (A) |
190 |
190 |
| Max. Discharging Current (A) |
190 |
190 |
| Charging Strategy for Li-ion Battery
|
Self-adaption to BMS |
| Number of Battery Input |
1 |
| PV String Input Data
|
| Max. PV Access Power (W) |
15200 |
16000 |
| Max. PV Input Power (W) |
9880 |
10400 |
| Max. PV Input Voltage (V) |
500 |
| Start-up Voltage (V) |
125 |
| MPPT Voltage Range (V) |
150-425 |
| Rated PV Input Voltage (V) |
370 |
| Max. Operating PV Input Current (A) |
26+26 |
| Max. Input Short-Circuit Current (A)
|
34+34 |
| No. of MPP Trackers/ |
2/2+2 |
| No. of Strings MPP Tracker |
|
| AC Input/Output Data
|
| Rated AC Input/Output Active Power (W)
|
7600 |
8000 |
| Max. AC Input/Output Apparent Power (VA)
|
8360 |
8800 |
| Rated AC Input/Output Current (A) |
34.5/33 |
36.4/34.8 |
| Max. AC Input/Output Current (A) |
38/36.3 |
40/38.3 |
| Max. Continuous AC Passthrough (grid to load)
(A) |
50 |
| Peak Power (off-grid) (W) |
2 times of rated power, 10s |
| Power Factor Adjustment Range |
0.8 leading to 0.8 lagging |
| Rated Input/Output Voltage/Range (V)
|
220/230 0.85Un-1.1Un |
| Rated Input/Output Grid
Frequency/Range(Hz) |
50/45-55, 60/55-65 |
| Grid Connection Form |
L+N+PE |
| Total Current Harmonic Distortion THDi
|
<3% (of nominal power) |
| DC Injection Current |
<0.5% In |
| Equipment Protection
|
| Integrated |
DC Reverse Polarity Protection, AC Output
Overcurrent Protection, Thermal Protection, AC Output Overvoltage
Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter(optional), Anti-islanding Protection DC
Switch, Insulation Impedance Detection, Residual Current
Detection |
| Surge Protection Level |
TYPE II(DC), TYPE II(AC) |
| Interface |
| Communication Interface |
RS485/RS232/CAN |
| Monitor Mode |
GPRS/WIFI/Bluetooth/4G/LAN(optional)
|
